Body channel was operated on the previous product through the switch of the body. But body channel can be easily operated on the new product only by the remote control.
It shows clear 42 charts, including eyesight, astigmatic angle, binocular vision, heterophoria, stereopsis and so on, and the mask(vertical, horizontal, single).
The refined appearance, which shows LED lighting at the side of the product, will upgrade the optometry room.
| Charts | 42 EA |
| Distance of Projector | 2.5~8m |
| Chart magnification | 30 × (when projected at 5m distance) |
| Lamp | LED |
| Masks | 35EA (1 open mask, 5 horizontal line maksks, 8 vertical line masks, 21 single letter masks) |
| Filter | 1 Red/Green Filter |
| Chart rotation speed | average 0.21 sec (min. 0.092sec, max.0.324sec) |
| Power supply | AC100-240V, 50/60Hz |
| Power consumption | 60VA |
| Dimensions | HCP8000-L Main Body (Stand 제외) 202(W)×364(D)×172(H) mm |
| Remote Controller : 64(W) ×196(D)×20(H) mm |
|
| Weights | HCP8000-L (Stand 제외) 4.9 kg |
| Remote Controller. 160 g (Battery included) |
|
| Basic accessories | Product Body(HCP8000-L), Screen Remoto Controller, Table Stand, Dust Cover, Power Cable T wrench, Fuse, Lamp(HCP8000-L), Battery |
| Optional accessories | Red/Green glasses, Polarization glasses |
