Opto X Link Corneal Crosslinking System

Technical Specifications

• Fixation and Focusing Light: 640 nm Red Led
• UV source: 365 nm UV Led CLuster
• Available irradiance Range: 0,636mW/cm² to 6,366mW/cm²
• Maximum Feedback Error: <1% (Microprocessor-based system)
• Maximum Internal Power Meter Error: <5%
• UV Spot Diameter: Adjustable to 6mm, 8mm or 10mm
• Working Distance: 45mm ± 1 mm 10s to 30 min
• Pulse Duration: 10s to 30 min
• Display: Green - Alphanimeric electroliminiscence
• Interlock System: Integrated safety system
• Power Supply: 90 to 240V ~, 50/60Hz
• Weight: 6.5 Kg
• Emergency Stop Switch on Panel: Inluded
• Carrying Case: Included
• Protective Glasses: Included
• Stand: Optional
• Video Camera: Optional
