AMR 7005 AUTO PHOROPTER

Specifications:

• Sphere power: range:+16.75 to -19.00 diopters; step: 0.25 diopters
• Cylinder power: range: 0.00 to -6.00 diopters (0.00 to -8.00 diopters with additional lens of -2.00 diopters); step: 0.25 diopters
• Cylinder axis: 0 to 180, 5 step
• Cross cylinder: 25 diopters
• Rotary prisms: 0 to 20, min. 1 step
• Auxiliary lens dial: (O)-Open aperture (two positions)(R)-Retinoscopic lens,+1.50D (P)-Polarizing lens 45mm- left eye 135mm- right eye (WMV)or(RMV)-Maddox rod. Vertical white-left eye red-right eye (WMH)or(RMH)-Maddox rod. horizontal white-left eye red-right eye (RL)-Red lens(1.12-10.12D sphere(PH)-Pin hole (10) or (6) -10 base-in-left eye, 6 base-up-right eye (dissociating prisms) (+/-0.50)+/-0.50 fixed cross cylinder(0C)-Occluder
• P.D. adjustment: 48-75mm, 1mm as a step
• Standard accessory lenses: two 12D and -2.00 cylinder lenses,two plano lenses for sealing front opening
• Standard accessories: 1 near point card with holder and reading rod,dust cover, face shield, accessory case for lenses
• Dimensions: 318 x 293 x 96 (mm)
• Net weight: approx 5kg.
