2mm minimum measurable pupil diameter
Large-screen color LCD display (5.7") angle adjustable, for easy observation of examined eyes.
Electric lifting Chin-Rest.
Forced frictional head locking.
One-touch locking.
Head is locked by pressing button on the screen bottom, offering ease, security and safety.
Auto Cutter Printer
| Measuring Range |
|
||||||
| Pupil Distance | 30 ~ 85mm (1mm steps) | ||||||
| Vertex Distance | 0mm, 12mm, 13.75mm，15mm | ||||||
| Measuring time | 0.5sec | ||||||
| Cylinder Form | -,+,± | ||||||
| Auto Tracing Function Range | ±16mm (up and down direction only) | ||||||
| Min. Pupil Size | Ø 2.0mm | ||||||
| Chart | Auto fog | ||||||
| Display | 5 .7" TFT LCD | ||||||
| Thermal Printer | |||||||
| Power saving mode | change to screen saving after 5 or 15 minutes idling | ||||||
| Power Supply | 100 ~ 120v/200 ~ 240v,50/60Hz /90W | ||||||
| DIMENSIONS | 480 (L) *270 (W) *445 (H) MM ³ | ||||||
| WEIGHT | 17KG |
